4. Use «Up» or «Down» to set the time format.
5. Press «Enter».
The setting is applied.
6. Press «Escape» repeatedly to return to the main menu.
Set the pressure display units
Set the pressure unit for display:
Format Example
bar 5.5bar
hPa 5523hPa
MPa 0.55MPa
psi 80psi
at 5.6at
kPa
550 kPa
1)
"Hg
15 "Hg
2)
1)
SIGMA CONTROL 2 SCREW FLUID
2)
SIGMA CONTROL 2 SCREW VAC
Tab. 47 Possible settings for the pressure unit
Precondition Password access level 2 is activated.
1. Open the 5.1 <Configuration – General> menu.
2. Use «Up» or «Down» to select the Pressure unit line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.1 General
Menu
Time format hh:mm:ssAM/PM
·········
Pressure unit psi
Unit of pressure
Temperature unit °F
Unit of temperature
·········
Display lighting
3. Press «Enter».
The display for the set unit flashes.
4. Use «Up» or «Down» to set the unit.
5. Press «Enter».
The setting is applied.
6. Press «Escape» repeatedly to return to the main menu.
8 Initial Start-up
8.2 Setting the controller
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
65

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
