Message Explanation Output
Motor running Compressor motor running
IDLE The machine is running in IDLE mode
ON LOAD The machine is running in LOAD mode
Group alarm Fault has occurred
Group warning
continuous
At least one warning message has appeared. No new warnings
can be seen.
Group warning
interrupted
At least one warning message has appeared. Each new warning
is indicated by a short signal interruption.
Remote mode Informs you whether the «Remote control» key is active
Clock active Informs you whether the timer control for the compressor
(«Timer control» key lights up in green) is active
Clock contact Timer with which a relay/transistor output can be switched
EMERGENCY STOP Signals whether the EMERGENCY STOP push button has been
pressed
12)
Not for AIRTOWER
Tab. 74 Assigned output signals
8.11.1.1 DO functions menu
The requested message can be assigned to a free digital output (DOR orDOT).
Precondition Password access level 2 is activated.
1. Select the 5.7.1
<Configuration – I/O periphery – DO functions>
menu.
A menu containing a list of available messages and their assigned outputs is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.1 DO functions
Menu
Controller on
Active line
DOR1.05 ☐ ¦ Logic : +
DOT1.02 ☐ ¦ Logic : +
Compressor on
DOR1.03 ☐ ¦ Logic : +
DOT1.02 ☐ ¦ Logic : +
8.11.1.2 Assigning a message to an output
1. Select the required message with the «Up» or «Down» keys.
2. Press the «Down» key once.
Output DOR has been selected.
3. Press «Down» twice.
Output DOT has been selected.
8 Initial Start-up
8.11 Setting input and output signals
152
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE
