4. Press «Enter».
The output of the selected message flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.1 DO functions
Menu
Controller on
Active line
DOR1.05 ok ☐ ¦ Logic : +
Active line with assigned output
DOT1.02 ☐ ¦ Logic : +
Compressor on
DOR1.03 ☐ ¦ Logic : +
DOT1.02 ☐ ¦ Logic : +
5. Select a free output with the «Up» or «Down» key.
6. Press «Enter».
The setting is applied.
7. Press the «Right» key.
8. Press «Enter».
The check box will flash.
9. Press «Up» key.
The check box associated to the output is activated.
10. Press «Enter».
If the message is correctly assigned to the output and activated,
ok
is displayed.
11. If necessary, set the
Logic
option.
Result A message about the operational state is now sent via the assigned digital output.
You are missing an organized display of assigned output signals?
➤ Enter the selected output in table 74.
8.11.2 Output input signals on the display
In addition to the defined alarm and warning messages there are six additional freely selectable
input signals that can be used to display messages. A list of the alarm and warning messages is
provided in chapters 10.2 and 10.3. Please see the machine's wiring diagram for information on
free inputs.
An input signal can be classified as either a fault, a warning or an operational message. To sup‐
press any possible contact bounce or similar problems, the input signal can be delayed by an ad‐
justable period. This ensures that the signal must be apparent for a minimum period before it can
be processed as a message.
If an input signal is classified as fault, the controller goes into the alarm state and shuts down
the machine.
Overview
Use the
External messages
menu for specifying the settings.
■ Entering the message text
■ Assigning and activating the input
■ Setting the time delay
■ Setting the logic
8 Initial Start-up
8.11 Setting input and output signals
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
153
