KAESER SIGMA CONTROL 2 - Assigning and activating the output; Switching and;or triggering messages with thresholds

■ Assigning and activating the output
■ Selecting the message type
■ Activating the message
8.11.2.1 External messages menu
Precondition The electrical connection has been made.
Password access level 2 is activated.
1. Select the 5.7.3 <Configuration – I/O periphery – External messages> menu.
The External messages menu is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
5.7.3 External messages
Menu
▶1 External message 1
Active line with external message No. 1
▶2 External message 2
▶3 External message 3
▶4 External message 4
▶5 External message 5
▶6 External message 6
8.11.2.2 Entering the message text
In the below example we select External message 1 .
1. Use «Up» or «Down» to select the External message 1 line.
2. Press «Enter».
The External message 1 menu is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.3.1 External message 1
Menu
External message 1
Message text
DI1.06 ☐
No input assigned
td: 0s ¦ Logic : +
Logic
DOR1.04 ☐
Warning ☑
Message type (operational, alarm, warning)
3. Press «Enter».
The cursor is located at the first character of the message text.
A column with alphanumeric characters is displayed.
The selected character flashes.
4. Select the required character with the «Up» or «Down» keys.
5. Press the «Right» arrow.
The cursor jumps to the next position of the message text.
6. Enter the remaining characters of the message text in the same manner.
7. Press «Enter».
The message text has been entered.
8 Initial Start-up
8.11 Setting input and output signals
154
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE
