KAESER SIGMA CONTROL 2 User Manual

Parameters Explanation
Cut-in pressure
min
Display:
For design reasons, pressure can only be built up above this value.
12)
not for AIRTOWER
Tab. 53 Compressor pressure parameters
➤ Set the parameters according to the following specifications.
8.4.1 Displaying pressure parameters
Precondition Password access level 2 is activated.
Open the menu for pressure parameters.
1. Open the 5.2.2 <Configuration – Pressure control – Pressure settings> menu.
2. Press «Enter».
The Pressure settings menu is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.2 Pressure settings
Menu
Setpoint pressure
pA SP: 116psi ¦ SD: −7.3psi
Active line
pB SP: 109psi ¦ SD: −5.8psi
·········
System pressure low ☐
↓ < 72.5psi ¦ SD: 7.2psi
Display further parameters
1. Use «Up» or «Down» to select the Cut-in pressure min line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.2 Pressure settings
Menu
System pressure low ☐
↓ < 72.5psi ¦ SD: 7.2psi
ta: 600s
DOR1.03 ☐¦Logic: +
------------------------------
Cut-in pressure min : 72.5bar
Active line
2. Select further parameters with the «Up» and «Down» keys.
8 Initial Start-up
8.4 Adjusting the pressure parameters of the machine
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
87
