Page #179 background imageLoading...
Page #179 background image
Assigning an input
Press the «Remote control» key
Machine damage can result from acknowledging a fault message without remedying its
cause!
Find the failure cause.
Decide to acknowledge or not.
8.13.1 Setting the remote acknowledgement function
Precondition Password access level 2 is activated.
1. Select the 5.5
< Configuration – Acknowledgement >
menu.
2. Use «Up» or «Down» to select the
Remote mode
line.
3. Press the «DOWN» key.
4. Press «Enter».
The currently active operating mode flashes.
5. Use «Up» or «Down» to set the
Key + remote contact
input.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.5 Acknowledgement
Menu
Remote mode:
Key + remote contact
Active line with "Key + remote contact" setting
------------------------------
RC Ack DI1.07
Key remote : ☑
6. Press «Enter».
The setting is applied.
Result The Remote acknowledgement function is set.
8.13.2 Activating the remote control
Activating the remote control see chapter 8.2.13.
Result SIGMA CONTROL 2 remote control is activated.
8 Initial Start-up
8.13 Activating remote acknowledgement
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
169
