KAESER SIGMA CONTROL 2 User Manual

Set the slave number
You must set the slave address for the communication with the SIGMA AIR MANAGER.
When connected to a SIGMA AIR MANAGER, the slave address is determined as follows:
Compressor number used at SIGMA AIR MANAGER +102.
Precondition Access level 2 is activated.
1. Open the 8.2 <Communication – Com-Module> menu.
The Com-Module menu is displayed
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.2 Com-Module
Menu
Send/receive
Com-Module active : ☑
Active line
Reset : ☐
Slave No. : 103
·········
Communication error : ☑
2. Use «Up» or «Down» to select the SlaveNo. line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.2 Com-Module
Menu
Send/receive
Com-Module active : ☑
Reset : ☐
Slave No. : 103
Active line
·········
Communication error : ☑
3. Press «Enter».
The display for the slave address flashes.
4. Use «Up» or «Down» to set the slave address 104.
5. Press «Enter».
The setting is applied.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.2 Com-Module
Menu
Send/receive
Com-Module active : ☑
Reset : ☐
Slave No. : 104
Active line
·········
Communication error : ☑
Monitoring for communication malfunction is active.
Result Slave address 104 is set.
8 Initial Start-up
8.10 Configuring the machine for master control
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
129

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
