174 Keysight E4980A/AL Precision LCR Meter
Save/Recall
Saving/Recalling Instrument Configuration States
6-
Step 5. Press the SAVE softkey to save configuration states into the internal memory.
To recall configuration states from the internal memory:
Step 1. Press [Save/Recall].
Step 2. Use the cursor keys to select the MEDIA field.
Step 3. Press the INT softkey.
Step 4. Use the cursor keys to select the No. field (0 through 9) for your desired
register.
Step 5. Press the RECALL softkey to recall configurations from the internal memory.
Using a Hard Key to Recall States from the Internal Memory
You can also recall configuration states from a particular register in the internal
memory by pressing one of the following hard keys:
• If you have selected the No. field for a register that already contains
configuration states, new configuration states overwrite the existing
ones.
DC bias and DC source settings are automatically turned OFF.
If you attempt to recall configuration states under any of the following
conditions, an “Incompatible state file” warning message is displayed.
• The configuration states were saved under a different firmware version.
• The configuration states were saved from another E4980A/AL with a
different option(s) equipped.
If you attempt to recall configuration states under the following condition,
a “No data to load” error message is displayed.
• The checksum has failed.
Hard key Description
Recall A Recalls configuration states from register 0 (#0 in the No. field).
Recall B Recalls configuration states from register 1 (#1 in the No. field).
