Keysight E4980A User Manual

Keysight E4980A/AL Precision LCR Meter 255
Overview of Remote Control
Data Buffer Memory
Figure 8-18 Binary format (Buffer memory)
NL^END is not included in the number of bytes to transfer. For example,
the number of byte of “:MEM:DIM DBUF, 3”, is (8  4)  3 + 1 = 97 bytes.
㪼㪋㪐㪏㪇㪸㫌㪼㪈㪇㪉㪈
㩺 㪋
㪇 㪥㪣㪵㪜㪥㪛
㪥㫆㪅㩷㫆㪽㩷㪹㫐㫋㪼㫊
㫋㫆㩷㫋㫉㪸㫅㫊㪽㪼㫉
㪓㩷㪛㪘㪫㪘㩷㪘㩷㪕 㪓㩷㪛㪘㪫㪘㩷㪙㩷㪕 㪓㩷㪪㪫㪘㪫㪬㪪㩷㪕
㪓㩷㪙㪠㪥㩷㪥㫆㪅㪕
㫆㫉
㪓㩷㪠㪥㪆㪦㪥㪫㩷㪕
D[VGU
D[VGU D[VGU D[VGU D[VGU D[VGU D[VGU

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
