Kyocera TASKalfa 6501i - Page 110

2N8/2N7
1-2-78
Installing for cassette 3 and 4
1. Pull the cassette 3 forward.
2. Remove the four screws and then
remove the cassette 3.
Figure 1-2-115
3. Pull the cassette 4 forward.
4. Remove the four screws and then
remove the cassette 4.
Figure 1-2-116
Screw
Screw
Screw
Screw
Cassette 3
Screw
Screw
Screw
Screw
Cassette 4
