Kyocera TASKalfa 6501i - Page 43

2N8/2N7
1-2-11
5. Remove six tapes and then remove
three protect sheets.
Figure 1-2-14
6. Open the DP.
7. Remove four tapes and then remove
the sheet.
8. Remove the tape and then remove A2
papers.
9. Close the DP.
Figure 1-2-15
Protect sheet
Protect sheet
Tap e s
Tap e s
Tap e
Tap e
Tap e
Tap e
Tap e
Sheet
A2 paper
