2N8/2N7
1-2-15
7. Fit the arm hinge cover A and B using
the M4 x 8 screws (black).
Figure 1-2-23
8. Fit the operation mount cover C using
the M4 x 8 screws (black).
Figure 1-2-24
Arm hinge
cover B
Arm hinge
cover A
Screw
Operation mount
cover C
Screw
