2N8/2N7
1-2-20
1. Pull cassette 3 and 4 out.
2. Remove the lift plate stopper from each
cassette and attach it to the storage
location.
*: When moving the machine, attach the lift
plate in original position.
Figure 1-2-32
1. Rotate the lock lever of the paper size
guide A and remove the lever. Pull the
paper size guide A up and out.
Figure 1-2-33
Release of lift plate stopper (cassette 3 and 4)
Cassette
Lift plate
stopper
Loading paper (cassette 3 and 4)
Lock lever
Paper size guide A
Cassette
