2N8/2N7
1-5-94
11. Remove six screws and then remove
the operation PWB.
12. Check or replace the operation PWB
and refit all the removed parts.
Figure 1-5-148
Operation unit
Screws
Screw
Screw
Screw
Operation unit
Screw
