2N8/2N7
2-3-85
Connector Pin Signal I/O Voltage Description
YC1 1 FG - - Ground
Connected to
ISC PWB
2 ENG_PAGEST O 3.3 V DC Page set signal
3 ENG_RDY O 3.3 V DC Ready signal
4 ENG_SEL I 3.3 V DC Select signal
5 ENG_CLK I 0/3.3 V DC(pulse) Clock signal
6 ENG_SI I 0/3.3 V DC(pulse) Serial communication data signal
7 ENG_SO O 0/3.3 V DC(pulse) Serial communication data signal
8 DP_OPEN O 3.3 V DC DPOCSW: On/Off
9 NC(GND) - - Not used
10 GND - - Ground
11 GND - - Ground
12 GND - - Ground
13 NC(GND) - - Not used
14 24V I 24 V DC 24 V DC power input from ISCPWB
15 24V I 24 V DC 24 V DC power input from ISCPWB
16 24V I 24 V DC 24 V DC power input from ISCPWB
YC2 1 3.3V O 3.3 V DC 3.3 V DC power output to DPOLSW
Connected to
DP original
length
switch, DP
original
sensor, DP
lift sensor 2,
DP original
width switch
2 GND - - Ground
3 LNG_SW I 0/3.3 V DC DPOLSW: On/Off
4 LNG_CLK O 0/3.3 V DC(pulse) Clock signal
5
GND
-
-
Ground
6
SET_SW I
0/3.3 V DC
DPOS: On/Off
7
3.3V O 3.3 V DC 3.3 V DC power output to DPOS
8 ANODE O 3.3 V DC 3.3 V DC power output to DPLS2
9 GND - - Ground
10 LF_DNSW I 0/3.3 V DC DPLS2: On/Off
11 WIDE3 I 0/3.3 V DC DPOWS: On/Off
12 WIDE2 I 0/3.3 V DC DPOWS: On/Off
13 GND - - Ground
14 WIDE1 I 0/3.3 V DC DPOWS: On/Off
