YC5 1 FEED3_OUT2B O 0/24 V DC (pulse) DPOFM drive control signal
Connected to
DP feed
motor, DP
registration
motor, DP lift
motor
2 FEED1_OUT2A O 0/24 V DC (pulse) DPOFM drive control signal
3 FEED2_OUT1A O 0/24 V DC (pulse) DPOFM drive control signal
4 FEED4_OUT1B O 0/24 V DC (pulse) DPOFM drive control signal
5
RGST3_OUT2B O
0/24 V DC (pulse) DPRM drive control signal
6
RGST1_OUT2A O
0/24 V DC (pulse) DPRM drive control signal
7
RGST2_OUT1A O
0/24 V DC (pulse) DPRM drive control signal
8
RGST4_OUT1B O
0/24 V DC (pulse) DPRM drive control signal
9 LIFT3_OUT2B O 0/24 V DC (pulse) DPLM drive control signal
10 LIFT1_OUT2A O 0/24 V DC (pulse) DPLM drive control signal
11 LIFT2_OUT1A O 0/24 V DC (pulse) DPLM drive control signal
12 LIFT4_OUT1B O 0/24 V DC (pulse) DPLM drive control signal
YC6 1 24V O 24 V DC 24 V DC power output to DPILSW
Connected to
DP interlock
switch
2 NC - - Not used
3 R24V I 24 V DC 24 V DC power input from DPILSW
YC7 1 R24V O 24 V DC 24 V DC power output to DPFM1
Connected to
DP fan motor
1
2
FAN_REM1 O 0/24 V DC DPFM1: On/Off
YC8 1 R24V O 24 V DC 24 V DC power output to DPFM2
Connected to
DP fan motor
2
2
FAN_REM2 O 0/24 V DC DPFM2: On/Off
YC10 1 CIS_TMG_SW I 0/3.3 V DC DPCS: On/Off
Connected to
SHD PWB
2 SHD_CLK O 0/3.3 V DC(pulse) Clock signal
3 SHD_SO O 0/3.3 V DC(pulse) Serial communication data signal
4 SHD_SEL O 0/3.3 V DC Select signal
5 SHD_PAGEST O 0/3.3 V DC Pageset signal
6 RESETN O 0/3.3 V DC Reset signal
7 SHD_OVMON I 0/3.3 V DC OVMON signal
8 SHD_SI I 0/3.3 V DC(pulse) Serial communication data signal
9 SHD_RDY I 0/3.3 V DC Ready signal
10 NC - - Not used
11 24V O 24 V DC 24 V DC power output to SHDPWB
12 24V O 24 V DC 24 V DC power output to SHDRWB
13 GND - - Ground
14 GND - - Ground
Connector Pin Signal I/O Voltage Description
