Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 205
Point Type Examples
Max Z
Finds the point with the maximum Z value in the region of
interest.
Min Z
Finds the point with the minimum Z value in the region of
interest.
Min X
Finds the point with the minimum X value in the region of
interest.
Max X
Finds the point with the maximum X value in the region of
interest.
Average
Determines the average location of points in the region of
interest.
Corner
Finds a dominant corner in the region of interest, where corner
is defined as a change in profile slope.
Top Corner
Finds the top-most corner in the region of interest, where corner
is defined as a change in profile shape.
Bottom Corner
Finds the bottom-most corner in the region of interest, where
corner is defined as a change in profile shape.
