Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 414
Point from Three Planes
The Point from three planes output type takes three plane geometric features as input and creates a
point at their intersection.
The X, Y, and Zmeasurements return the position of the intersect point. The X, Y, and Z Angle
measurements return 0.000 values.
A point generated at the intersection of two planes. The Y position is indicated here.
Point or Line
The Point and Line types of output take a point or a line geometric feature as input, respectively.
For point output, the X, Y, and Zmeasurements return the X, Y, and Z position of the point; the angle
measurements all produce 0.000 as values.
