Gocator Line Profile Sensors: User Manual
Specifications • 781
Function Pin
Reserved 6
Reserved 7
Reserved 8
GND (output for powering other devices) 9
+5VDC (output for powering other devices) 10
The Input connector does not need to be wired up for proper operation.
For Input connection wiring options, see Input on page 784.
Function Pin
Encoder_A_Pin_1 1
Encoder_A_Pin_2 2
Encoder_A_Pin_3 3
Encoder_B_Pin_1 4
Encoder_B_Pin_2 5
Encoder_B_Pin_3 6
Encoder_Z_Pin_1 7
Encoder_Z_Pin_2 8
Encoder_Z_Pin_3 9
GND (output for powering external devices) 10
+5VDC (output for powering external devices) 11
Encoder (11 pin connector)
For Encoder connection wiring options, see Encoder on the next page.
Electrical Specifications
Specification Value
Power Supply Voltage +24 VDCto +48 VDC
Power Supply Current (Max.)* Master 810:9 A
Master 2410:25 A
* Fully loaded with 1 Aper sensor port.
Power Draw (Min.) Master 810:1.7 W
Master 2410:4.8 W
Safety Input Voltage Range +24 VDCto +48 VDC
Encoder Signal Voltage Differential (5 VDC, 12 VDC)
Electrical Specifications
