Gocator Device Files • 506
Element Type Description
Y 64f Y value of region.
Width 64f Width value of region.
Length 64f Length value of region.
Element Type Description
X 64f X value of region.
Y 64f Y value of region.
Z 64f Z value of region.
Width 64f Width value of region.
Length 64f Length value of region.
Height 64f Height value of region.
ZAngle 64f ZAngle value of region.
GDKParameter Surface Region 3D Type
Element Type Description
32s Geometric feature Id for parameter.
GDKParameter Geometric Feature Type
ProfileArea
A ProfileArea element defines settings for a profile area tool and one or more of its measurements.
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileArea above.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
ProfileArea Child Elements
