Gocator Line Profile Sensors: User Manual
Gocator Device Files • 565
Gocator 2500 series sensors do not support the Selcom Serial Protocol.
Element Type Description
Serial.used Boolean Indicates if the output is available on the sensor.
Protocol 32s
Serial protocol:
0 – ASCII
1 – Selcom
Protocol.options 32s (CSV) List of available protocols.
Selcom Section
See Selcom below.
Ascii Section
See Ascii below.
Measurements 32u (CSV) Selected measurement sources.
Measurements.options 32u (CSV) List of available measurement sources.
Serial Child Elements
Selcom
Element Type Description
Rate 32u Output bit rate.
Rate.options 32u (CSV) List of available rates.
Format 32s
Output format:
0 – 12-bit
1 – 12-bit with search
2 – 14-bit
3 – 14-bit with search
Format.options 32s (CSV) List of available formats.
DataScaleMin 64f Measurement value corresponding to minimum word value.
DataScaleMax 64f Measurement value corresponding to maximum word value.
Delay 64u Output delay in µs.
Selcom Child Elements
Ascii
Element Type Description
Rate 32u Output bit rate.
Rate.options 32u (CSV) List of available rates.
Delimiter String Field delimiter.
Terminator String Line terminator.
InvalidValue String String for invalid output.
CustomDataFormat String Custom data format.
Ascii Child Elements
