Gocator Line Profile Sensors: User Manual
Specifications • 789
Function Pin
Input 1 1
Input 1 GND 2
Reserved 3
Reserved 4
Reserved 5
Reserved 6
Reserved 7
Reserved 8
Reserved 9
Reserved 10
Reserved 11
Reserved 12
Input (12 pin connector)
The Input connector does not need to be wired up for proper operation.
Function Pin
Encoder_A+ 1
Encoder_A- 2
Encoder_B+ 3
Encoder_B- 4
Encoder_Z+ 5
Encoder_Z- 6
GND 7
+5VDC 8
Encoder (8 pin connector)
Master 1200/2400 Electrical Specifications
Specification Value
Power Supply Voltage +48 VDC
Power Supply Current (Max.) 10 A
Power Draw (Min.) 5.76 W
Safety Input Voltage Range +24 VDCto +48 VDC
Encoder Signal Voltage Differential (5 VDC)
Digital Input Voltage Range Logical LOW: 0 to +0.1 VDC
Logical HIGH: +3.5 to +6.5 VDC
Electrical Specifications
When using a Master hub, the chassis must be well grounded.
