Gocator Line Profile Sensors: User Manual
Gocator Device Files • 503
Element Type Description
13 – Median
RegionEnabled Bool
Indicates whether feature detection applies to the defined
Region or to the entire active area.
Region
ProfileRegion2D
Element for feature detection area.
ProfileLine
An element of type ProfileLine defines measurement areas used to calculate a line.
Element Type Description
RegionCount 32s Count of the regions.
Regions (Collection) The regions used to calculate a line. Contains one or two Region elements
of type ProfileRegion2D, with RegionEnabled fields for each.
ProfileLine Child Elements
ProfileRegion2d
An element of type ProfileRegion2d defines a rectangular area of interest.
Element Type Description
X 64f
Setting for profile region X position (mm).
Z 64f
Setting for profile region Z position (mm).
Width 64f
Setting for profile region width (mm).
Height 64f
Setting for profile region height (mm).
ProfileRegion2d Child Elements
SurfaceTypes
The following types are used by the various measurement tools.
Region3D
An element of type Region3D defines a rectangular area of interest in 3D.
Element Type Description
X 64f Volume X position (mm).
Y 64f Volume Y position (mm).
Z 64f Volume Z position (mm).
Width 64f Volume width (mm).
Length 64f Volume length (mm).
Height 64f Volumeheight (mm).
Region3D Child Elements
SurfaceFeature
An element of type SurfaceFeature defines the settings for detecting a feature within an area of interest.
