Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 363
Sphere
The Sphere tool lets you compute characteristics of a scanned sphere by specifying a region to inspect.
For example, you can use the tool to align a robot-mounted sensor to a ball-bar as shown in the images
below.
For the tool to work properly, the tool's region typically must be enabled and set, and properly
placed. For more information, see the table of parameters below.
2DView 3DView
Measurement Panel
For information on adding, managing, and removing tools and measurements, as well as detailed
descriptions of settings common to most tools, see Tools Panel on page 198.
