Gocator Device Files • 523
Element Type Description
EdgeAngle 64f Edge angle.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Edge region.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Axis
(Gap measurement only)
32s
Measurement axis:
0 – Edge
1 – Surface
2 – Distance
Absolute
(Flush measurement only)
Boolean
Setting for selecting absolute or signed result:
0 – Signed
1 – Absolute
Gap/Flush Measurement
ProfilePosition
A ProfilePositionelement defines settings for a profile position tool and one or more of its
measurements.
