LMI Technologies Gocator 2500 Series User Manual

Gocator Line Profile Sensors: User Manual
Gocator Device Files • 513
Element Type Description
Measurements\MaxErrorZ CircleMeasurement Maximum error Z measurement
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Circle Tool Measurement
ProfileDimension
A ProfileDimension element defines settings for a profile dimension tool and one or more of its
measurements.
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
ProfileDimension Child Elements
