Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 400
Measurements, Data, and Settings
Measurement
Running Time (ms)
The amount of time required for tool execution. Used for diagnostic purposes.
Measurements
Type Description
Transformed Surface The transformed surface. Available via the Stream drop-
down in other tools.
Data
Parameter Description
Source The sensor, or combination of sensors, that provides data for the tool's
measurements. For more information, see Source on page 201.
Input Plane The plane the tool uses to transform the surface scan data.
Input Line The line the tool uses to transform the surface scan data.
Input Point The point the tool uses to transform the surface scan data.
Scaling Mode One of the following:
l Original Resolution
l HighOriented (uniform)
l Low Oriented (uniform)
l Optimal (uniform)
Add Fixed Transform When enabled, displays X, Y, and Z offset and angle fields you can use to set
additional transformations, which are applied after the transformation supplied
by the input geometric features.
Setting a fixed transformation can be useful if the geometric features the tool
uses results in data rotated to an unusual orientation; you could, for example,
rotate the data 90 or 180 degrees so that it is in the "expected"orientation, or
shift it so that it's easier to work with.
Use Region When this setting is enabled, the tool only outputs the surface contained in the
defined region.
Filters The filters that are applied to measurement values before they are output. For
more information, see Filters on page 209.
Decision The Max and Min settings define the range that determines whether the
measurement tool sends a pass or fail decision to the output. For more
information, see Decisions on page 208.
Parameters
Anchor Description
X, Y, or Z Lets you choose the X, Y, or Z measurement of another tool
to use as a positional anchor for this tool.
Anchoring
