Gocator Device Files • 551
SurfaceStud
A SurfaceStudelement defines settings for a surface stud tool and one or more of its measurements.
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See Feature Child Elements on page 553.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
StudRadius 64f Radius of stud (mm).
StudHeight 64f Height of stud (mm).
BaseHeight 64f Height of stud’s base.
TipHeight 64f Height of stud’s tip.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
SurfaceStudChild Elements
