Gocator Device Files • 512
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileCircle on the previous page.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Circle tool
measurement
X measurement.
Measurements\Z Circle tool
measurement
Z measurement.
Measurements\Radius Circle tool
measurement
Radius measurement.
Measurements\StdDev CircleMeasurement Standard deviation measurement
Measurements\MinError CircleMeasurement Minimum error measurement
Measurements\MinErrorX CircleMeasurement Minimum error X measurement
Measurements\MinErrorZ CircleMeasurement Minimum error Z measurement
Measurements\MaxError CircleMeasurement Maximum error measurement
Measurements\MaxErrorX CircleMeasurement Maximum error X measurement
ProfileCircle Child Elements
