Page #254 background image
Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 254
Parameter Description
Ref Line Used to define the reference line when Line is selected in
the Reference Type parameter. To set the region (or regions)
of the reference line, adjust it graphically in the data viewer,
or expand the feature using the expand button ( ) and
enter the values in the fields. For more information on
regions, see Regions on page 201.
For more information on fit lines, see Fit Lines on page 208.
Angle Range
(Angle measurement only)
Determines the angle range. The options are:
-90 – 90
0 – 180
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
209.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
208.
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
