Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 257
Measurement Illustration
Max Error X
Max Error Z
Finds the best-fitted line and returns the X or Z position of
the maximum error from the line (the maximum distance
above the line).
Type Description
Line
The fitted line.
Error Min Point
The point of minimum error.
Error Max Point
The point of maximum error.
Features
For more information on geometric features, see Geometric Features on page 206.
Parameter Description
Source The sensor, or combination of sensors, that provides data
for the tool's measurements. For more information, see
Source on page 201.
Stream The data that the tool will apply measurements to.
In Surface mode, this setting is only displayed when a
section is defined on the surface data.
For more information on sections, see Sections on page 190.
Region The region to which the tool's measurements will apply. For
more information, see Regions on page 201.
Parameters
