Page #264 background imageLoading...
Page #264 background image
Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 264
Parameter Description
Feature The feature the tool uses for its measurements. One of the
following:
l Max Z
l Min Z
l Max X
l Min X
l Corner
l Average
l Rising Edge
l Falling Edge
l Any Edge
l Top Corner
l Bottom Corner
l Left Corner
l Right Corner
l Median
To set the region of a feature, adjust it graphically in the
data viewer, or expand the feature using the expand
button ( ) and enter the values in the fields. For more
information on regions, see Regions on page 201.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
209.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
208.
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
