Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 326
Parameter Description
Grid Cell to Display
(used with Grid Pattern
region mode)
When the Global Flatness measurement is selected, displays data points in the specified cell.
Display Points in Region must be enabled for this to work. (When a local measurement is
selected, changing this value has no effect.)
Unit Lets you choose which units the tool uses for measurement results. One of the following:
l um (micrometers)
l mm (millimeters)
Filters The filters that are applied to measurement values before they are output. For more information,
see Filters on page 209.
Decision The Max and Min settings define the range that determines whether the measurement tool
sends a pass or fail decision to the output. For more information, see Decisions on page 208.
Anchor Description
X, Y, or Z Lets you choose the X, Y, or Z measurement of another tool
to use as a positional anchor for this tool.
Z angle Lets you choose the Z Angle measurement of another tool to
use as an angle anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
