Gocator Line Profile Sensors: User Manual
Gocator Device Files • 509
Element Type Description
all available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\GlobalX Bounding Box tool
measurement
GlobalX measurement
Measurements\GlobalY Bounding Box tool
measurement
GlobalY measurement
Measurements\GlobalAngle Bounding Box tool
measurement
GlobalAngle measurement
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature.
Features\CornerPoint GeometricFeature CornerPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
Bounding Box Tool Measurement
