Gocator Line Profile Sensors: User Manual
Gocator Device Files • 518
Element Type Description
RefType 32s
Reference line type:
0 – Fit
1 – X Axis
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefLine
ProfileLine
Definition of reference line. Ignored if RefType is not 0.
Line
ProfileLine
Definition of line.
Measurements\X Intersect tool
measurement
X measurement.
Measurements\Z Intersect tool
measurement
Z measurement.
Measurements\Angle Intersect tool
measurement
Angle measurement.
Features\IntersectPoint
GeometricFeature
IntersectPoint PointFeature.
Features\Line GeometricFeature Line LineFeature.
Features\BaseLine GeometricFeature BaseLine LineFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
Intersect Tool Measurement
