Gocator Device Files • 533
Element Type Description
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
NominalBevelAngle 64f Nominal bevel angle (mm).
NominalOuterRadius 64f Nominal outer radius (mm).
NominalInnerRadius 64f Nominal inner radius (mm).
BevelRadiusOffset 64f Bevel radus offset (mm).
Shape 32s The shape of the countersunk hole:
0 – Cone
1 – Counterbore
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions which are to be used
RefRegions (Collection)
Reference regions. Contains 2 SurfaceRegion2D elements.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction:
0 – Disable
1 – Enable
