Gocator Line Profile Sensors: User Manual
Gocator Device Files • 548
Element Type Description
4 – Section
Stream\Id 32u The stream source ID.
RegionsEnabled Boolean
Setting to enable/disable regions:
0 – Disable
1 – Enable
RegionCount 32s Count of the regions.
Regions (Collection) Measurement regions. Contains up to four Region elements
of type Region3D.
Measurements\XAngle Plane tool
measurement
XAngle measurement.
Measurements\YAngle Plane tool
measurement
YAngle measurement.
Measurements\ZOffset Plane tool
measurement
ZOffset measurement.
Measurements\StdDev Plane tool
measurement
Standard deviation measurement
Measurements\MinError Plane tool
measurement
Minimum error measurement
Measurements\MaxError Plane tool
measurement
Maximum error measurement
Measurements\XNormal PlaneMeasurement XNormal measurement
Measurements\YNormal PlaneMeasurement YNormal measurement
Measurements\ZNormal PlaneMeasurement ZNormal measurement
Measurements\Distance PlaneMeasurement Distance from normal measurement
Features\Plane
GeometricFeature
Resulting plane PlaneFeature.
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
Plane Tool Measurement
