LS Industrial Systems XG5000 User Manual

Chapter 3 Project
3-27
3.4.3 Export to file
The following items can be saved as separate item files.
Item File Extension
PLC cfg
Global/direct variables gdv
I/O parameter iop
Basic parameter bsp
Program prg
Use function/function block fun
1) PLC
[Steps]
1. On the project window, select the PLC Item.
2.Select [Project] – [Export to File]-[PLC] on the menu.
3. Input the file name, and then click [OK].
2) Variable/Comment
[Steps]
1. On the project window, select the Variable/Comment Item.
2. Select [Project] - [Export to File]-[Variable/Comment] on the menu.
3. Input the file name, and then click [OK].
