LS Industrial Systems XG5000 User Manual

Chapter 1 Introduction
1-1
Chapter 1 Introduction
1.1 Features of XG5000
XG5000 is a software tool designed to program and debug XGT PLC series with the following features and
merits
(1) Multi-PLC, Multi-Program
Allows the user to edit, monitor or manage PLC system interlocked with several PLC included in a project at
the same time.
And the program can be made as divided into Scan programs and various Task programs
(2) Various Drag and Drop
Makes editing easy and convenient with Drag and Drop function on most of editors such as Project, Variable/
Comment, LD Edit, Variable Monitor, etc.
(3) Setting User’s Shortcut Keys
Shortcut Keys provided as default can be changed or added as specified as familiar to a user
(4) Various Message Windows
Provides various message windows to edit and inspect program easily.
(5) Convenient Variable/Comment Editing
- Edit with MS Excel is available.
- Various types of Edit is available through View Variable, View Device, View Flag, etc.
- Similar kind of Variables can be added easily with Auto-fill.
- Convenient Copy is available on different Variable/Comment Windows with Drag and Drop
- Direct Edit is available without displaying dialog box just like Excel.

LS Industrial Systems XG5000 Specifications

General

Manufacturer	LS Industrial Systems
Model	XG5000
Category	Controller
Simulation	Yes
Memory Capacity	Varies by PLC model
I/O Capacity	Varies by PLC model
Dimensions	Varies by PLC model
Weight	Varies by PLC model
Type	Programming Tool
Supported PLC Series	XGB, XGI, XGR, XGK
Programming Languages	Ladder Diagram (LD), Instruction List (IL), Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)
Operating System	Windows
Communication Interface	RS-232, USB, Ethernet
Communication Protocols	Modbus RTU, Modbus TCP, Ethernet/IP, Modbus, LS Bus
