Chapter 6 SFC Edit
6-39
6.3.6 Devices/Comments
Displays variables or devices used in the contact, coil, function (block) as Devices/Comment. If variable
doesn’t have device, it displays variable name.
[Steps]
1. Select menu [View]-[Device/Comments].
Notes
- When changing the above option, it will take time according to program amount.
- When printing, Devices/Variables/Comments is supported. For more details, refer to the Ch. 14.
6.3.7 Adjust Contact No.
It is used to adjust the number of contact points displayed in the screen. Here, the number of contact points
is total number (horizontal cell - 1), excluding the output position.
[Steps]
1. Select [View]-[Change columns]-[contact no.] on the menu.
If the data in the very right of the present screen is larger than the number of contact points to display, it may
be displayed by rung including arrow.
