LS Industrial Systems XG5000 User Manual

Chapter 16 XG-SIM
16-18
16.2.4 Module Simulation
XG-SIM provides a simple simulation function for I/O module and special module. In case of digital I/O module, it supports I/O function
for I or Q area; in case of special module, it supports the monitoring function for analogue value receiving from or sending to outside.
1) Module setting
The module simulation function provided by XG-SIM uses the information set in the I/O parameter of XG5000. Therefore, it is necessary
to set a module in the I/O parameter to simulate the module and reflect to a program.

LS Industrial Systems XG5000 Specifications

General

Manufacturer	LS Industrial Systems
Model	XG5000
Category	Controller
Simulation	Yes
Memory Capacity	Varies by PLC model
I/O Capacity	Varies by PLC model
Dimensions	Varies by PLC model
Weight	Varies by PLC model
Type	Programming Tool
Supported PLC Series	XGB, XGI, XGR, XGK
Programming Languages	Ladder Diagram (LD), Instruction List (IL), Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)
Operating System	Windows
Communication Interface	RS-232, USB, Ethernet
Communication Protocols	Modbus RTU, Modbus TCP, Ethernet/IP, Modbus, LS Bus
