Chapter 1 Introduction
1-9
1.4 Installation of USB Device Driver
If XG5000 has been installed on Windows XP for the first time, USB device driver shall be additionally
installed. Although USB connection is not available, USB device driver shall be also installed as described
below.
Notes
In case of installing the XG5000 while PC is being connected with PLC through USB, USB device driver
installation window appears automatically. (refer to CH1.3, 10)
[Steps]
1. Ensure that Drivers folder is created in the folder where XG5000 is installed, and there are 2 driver files of
GmUSBD.sys and GmUSBD.inf in the Drivers folder. If there is no folder or driver file, reinstall XG5000.
2. Turn PLC Power on and connect USB connector with PC. If connection is established, Found New
Hardware Wizard Dialog Box will be displayed to ask you to install the device driver.
To Next Page
