Chapter 6 SFC Edit

6-6

Notes

- Label can be inputted when selecting step or block.

- Label is inputted ahead of the selected step or block.

6.2.6 Input Jump

Inputs Jump.

[Steps]

1. Move the cursor to the location you want edit

2. On the tool box, select the Jump to input and then click the edit area. Or click the Shortcut Key applicable

to symbol.

3. New jump is inputted.
