Chapter 19 Exclusive Functions for Event Input Module
19-8
19.2.3 SOE Event History Window
The SOE monitor displays the XGF-SOEA module SOE event history window automatically when connected
with PLC CPU.
Double-click on the desired module to run the event monitor window.
[Dialog]
[Dialog] description;
a. CPU event history: select the event saved in the CPU module.
b. Module event history: select the event saved in the SOE module.
c. Double-click on the CPU event history or module event history to activate the event monitor window.
a
b
