Manual Torque Boost Setting Details
Set torque boost for forward operation.
Set torque boost for reverse operation.
Excessive torque boost will result in over-excitation and motor overheating .
Auto Torque Boost-1
Auto torque boost enables the inverter to automatically calculate the amount of output
voltage required for torque boost based on the entered motor parameters. Because auto
torque boost requires motor-related parameters such as stator resistance, inductance, and
no-load current, auto tuning (bA.20) has to be performed before auto torque boost can be
configured [Refer to 5.9 Auto Tuning on page 183]. Similarly to manual torque boost,
configure auto torque boost while running a load that requires high starting torque, such as
lift-type loads.
