LSIS LSLV-S100 User Manual

149
Learning Basic Features
Slave Parameter
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
CM
01
Station ID
Int485 St ID
3
3–99
-
95
P2P
communication
options
Int 485 Func
3
KPD-Ready
0–3
-
Multi-keypad Setting Details
Code
Description
CM.01 Int485 St ID
Prevents conflict by designating a unique identification value to an
inverter.
Values can be selected from numbers between 3–99.
CM.95 Int 485
Func
Set the value to 3(KPD-Ready) for both master and slave inverter
CNF-03 Multi KPD
ID
Select an inverter to monitor from the group of inverters.
CNF-42 Multi key
Sel
Select a multi-function key type 4(Multi KPD) .
• Multi-keypad (Multi-KPD) features work only with code version 1.00, IO S/W version 0.11,
and keypad S/W version 1.07 or higher versions.
• The multi-keypad feature will not work when the multi-keypad ID (CNF-03 Multi-KPD ID)
setting is identical to the RS-485 communication station ID (CM-01 Int485 st ID) setting.
• The master/slave setting cannot be changed while the inverter is operating in slave mode.
4.23 User Sequence Setting
User Sequence creates a simple sequence from a combination of different function blocks.
The sequence can comprise of a maximum of 18 steps using 29 function blocks and 30
void parameters.
1 Loop refers to a single execution of a user configured sequence that contains a maximum
of 18 steps. Users can select a Loop Time of between 10-1,000ms.
The codes for user sequences configuration can be found in the US group (for user
sequence settings) and the UF group (for function block settings). US, UF groups are
displayed when the code AP.02 is set to 1.
