Technical Specification
30-75kW Models
Product
(kW)
AC Input Fuse
AC Reactor
Current (A)
Voltage (V)
Inductance(mH)
Current(A)
30 kW-4
125 A
600
0.29
69
37 kW-4
0.24
85
45 kW-4
160 A
0.20
100
55 kW-4
200 A
0.15
134
75 kW-4
0.13
160
Only use Class H or RK5, UL listed input fuses and UL listed circuit breakers. See the table
above for the voltage and current ratings for fuses and circuit breakers.
Utiliser UNIQUEMENT des fusibles d’entrée homologués de Classe H ou RK5 UL et des
disjoncteurs UL. Se reporter au tableau ci-dessus pour la tension et le courant nominal des
fusibless et des disjoncteurs.
11.6 Terminal Screw Specification
Input/Output Terminal Screw Specification
11.6.1.1 0.4-22kW Models
Product (kW)
Terminal Screw Size
Screw Torque (Kgf  cm/Nm)
Single phase
200V
0.4
M3.5
2.1-6.1/0.2-0.6
0.75
1.5
2.2
M4
3-phase
200V
0.4
M3.5
0.75
1.5
2.2
