LSIS LSLV-S100 - User Sequence Function Group(UF)

Table of Functions
355
Code
Comm.
Address
Name
LCD Display
Setting
Range
Initial
Value
Property*
V/
F
SL
Ref.
setting18
49
0h1D31
Input constant
setting19
Void Para19
-9999-9999
0
X/A
O
I/P
p.149
50
0h1D32
Input constant
setting20
Void Para20
-9999-9999
0
X/A
O
I/P
p.149
51
0h1D33
Input constant
setting21
Void Para21
-9999-9999
0
X/A
O
I/P
p.149
52
0h1D34
Input constant
setting22
Void Para22
-9999-9999
0
X/A
O
I/P
p.149
53
0h1D35
Input constant
setting23
Void Para23
-9999-9999
0
X/A
O
I/P
p.149
54
0h1D36
Input constant
setting24
Void Para24
-9999-9999
0
X/A
O
I/P
p.149
55
0h1D37
Input constant
setting25
Void Para25
-9999-9999
0
X/A
O
I/P
p.149
56
0h1D38
Input constant
setting26
Void Para26
-9999-9999
0
X/A
O
I/P
p.149
57
0h1D39
Input constant
setting27
Void Para27
-9999-9999
0
X/A
O
I/P
p.149
58
0h1D3A
Input constant
setting28
Void Para28
-9999-9999
0
X/A
O
I/P
p.149
59
0h1D3B
Input constant
setting29
Void Para29
-9999-9999
0
X/A
O
I/P
p.149
60
0h1D3C
Input constant
setting30
Void Para30
-9999-9999
0
X/A
O
I/P
p.149
80
0h1D50
S
Analog input 1
P2P In V1
0-12,000
-/A
O
I/P
p.149
81
0h1D51
Analog input2
P2P In I2
-12,000-
12,000
-/A
O
I/P
p.149
82
0h1D52
Digital input
P2P In DI
0-0x7F
-/A
O
I/P
p.149
85
0h1D55
Analog output
P2P OutAO1
0-10,000
0
X/A
O
I/P
p.149
89
0h1D58
Digital output
P2P OutDO
0-0x03
0
X/A
O
I/P
p.149
8.13 User Sequence Function group(UF)
This group appears when AP.02 is set to 1 (Yes) or CM.95 is set to 2 (P2P Master). The
parameter cannot be changed while the user sequence is running.
SL: Sensorless vector control function (dr.09) , I – IM Sensorless, P – PM Sensorless
*O/X: Write-enabled during operation, 7/L/A: keypad/LCD keypad/common
Code
Comm.
Address
Name
LCD
Display
Setting Range
Initial
Value
Property*
V/
F
SL
Ref.
