RS-485 Communication Features
279
Total Memory Map for Communication
Communication Area
Memory Map
Details
Communication common compatible
area
0h0000-
0h00FF
iS5, iP5A, iV5, iG5A compatible area
Parameter registration type area
0h0100-
0h01FF
Areas registered at CM.31–38 and
CM.51–58
0h0200-
0h023F
Area registered for User Group
0h0240-
0h027F
Area registered for Macro Group
0h0280-
0h02FF
Reserved
S100 communication common area
0h0300-
0h037F
Inverter monitoring area
0h0380-
0h03DF
Inverter control area
0h03E0-
0h03FF
Inverter memory control area
0h0400-
0h0FFF
Reserved
0h1100
dr Group
0h1200
bA Group
0h1300
Ad Group
0h1400
Cn Group
0h1500
In Group
0h1600
OU Group
0h1700
CM Group
0h1800
AP Group
0h1B00
Pr Group
0h1C00
M2 Group
Parameter Group for Data Transmission
By defining a parameter group for data transmission, the communication addresses
registered in the communication function group (CM) can be used in communication.
Parameter group for data transmission may be defined to transmit multiple parameters at
once, into the communication frame.
Group
Code
Name
LCD Display
Parameter Setting
Setting
range
Unit
CM
31-38
Output communication
address x
Para Status-x
-
-
0000-FFFF
Hex
51-58
Input communication
address x
Para Control-
x
-
-
0000-FFFF
Hex
