9 Troubleshooting
This chapter explains how to troubleshoot a problem when inverter protective functions,
fault trips, warning signals, or a fault occurs. If the inverter does not work normally after
following the suggested troubleshooting steps, please contact the LSIS customer service
center.
9.1 Trips and Warnings
When the inverter detects a fault, it stops the operation (trips) or sends out a warning signal.
When a trip or warning occurs, the keypad displays the information briefly. If the LCD
keypad is used, detailed information is shown on the LCD display. Users can read the
warning message at Pr.90. When more than 2 trips occur at roughly the same time, the
keypad (basic keypad with 7-segment display) displays the higher priority fault trip
information, while the LCD keypad shows the information for the fault trip that occurred first.
The fault conditions can be categorized as follows:
• Level: When the fault is corrected, the trip or warning signal disappears and the fault is
not saved in the fault history.
• Latch: When the fault is corrected and a reset input signal is provided, the trip or warning
signal disappears.
• Fatal: When the fault is corrected, the fault trip or warning signal disappears only after
the user turns off the inverter, waits until the charge indicator light goes off, and turns the
inverter on again. If the the inverter is still in a fault condition after powering it on again,
please contact the supplier or the LSIS customer service center.
Fault Trips
Protection Functions for Output Current and Input Voltage
Displayed when the motor overload trip is activated and
the actual load level exceeds the set level. Operates
when Pr.20 is set to a value other than 0.
Displayed when the motor underload trip is activated
and the actual load level is less than the set level.
Operates when Pr.27 is set to a value other than 0.
Displayed when inverter output current exceeds 200%
of the rated current.
